UTL on grid solar inverter 8 kw

UTL on grid solar inverter 8 kw Description

our top-of-the-line 8 kW UTL On Grid Solar Inverter, perfect for those seeking high-quality, reliable power solutions. This state-of-the-art inverter boasts a robust design and seamless performance, making it the best choice for your solar energy needs. With a price that will pleasantly surprise you, this inverter is a true standout in the market.
Experience the power of this 8 kW UTL On Grid Solar Inverter, designed to exceed expectations and deliver exceptional results. Whether you are a professional installer or a DIY enthusiast, this inverter is sure to impress with its easy installation and user-friendly features. Available at our shop in Delhi, Noida, Ghaziabad, Gurugram, Faridabad, this inverter is also offered at wholesale prices for our esteemed distributors.
As the leading distributor of solar inverters in India, we are proud to offer this 8 kW UTL On Grid Solar Inverter at a special discounted price. Our trusted dealers can enjoy exclusive benefits and free shipping on their orders. Don't miss out on this incredible sale - buy now and elevate your solar energy experience with this top-of-the-line model.

UTL on grid solar inverter 8 kw Specifications

Brand                                         UTL

Modal No                                  UTL 8 F3 GT

Max. DC Input Power               10.4 KW

Max. DC Input Voltage             1000 V

Start Up DC Input Voltage        140 V

MPPT Operating Range           120~850 V

Max. DC Input Current             13+13 A

Max. Short Circuit Current       19.5+19.5 A

No. of MPP Tracker                   2

No. of String par MPP Tracker 1

Rated Output Power                  8 KW

Max. Active Power                     8.8 KW

Nominal Output Voltage           3L/N/PE 220/380,230/400V                                                                     (Optional)

Rated Grid Frequency                50/60 Hz (Optional)

Operating Phase                        3 Phase

Rated AC Grid Output Current  12.1/11.6 A

Max. AC Output Current            13.3/12.8 A

Output Power Factor                  0.8 leading to 0.8 lagging

Grid Current                                 <3%

DC Injection Current                    <0.5% (mA)

Grid Frequency Range                 50/60Hz

Max. Efficiency                             97.3%

Euro Efficiency                              97.1%

MPPT Efficiency                            >99%

DC Reverse-Polarity Protection    Yes

AC Short Circuit Protection           Yes

AC Output Overcurrent                 Yes

Output Overvoltage Protection    Yes

Insulation Resistance Protection   Yes

Ground Fault Monitoring               Yes

Anti-islanding Protection               Yes

Temperature Protection                  Yes

Integrated DC Switch                       Yes

Remote Software Update                Yes

Remote Change of                           Yes

Surge Protection                              DC Type II/AC Type II (Rating Up to 20 KA)

Size                                                    330x457x185 mm (LxDxW)

Weight                                               10 kg

Technology                                        Transformer less

Internal Consumption                      <1W (Night)

Running Temperature                      -25~65 C, >45C Derating

Ingress Protection                             IP65

Noise Emission (Typical)                   <35 dB

Cooling Concept                                 Natural Cooling

Warranty                                              10 Years

DC Connection                                     MC-4 Matabele

AC Connection                                     IP65 Rated Plug

Display                                                  LCD 1602

Interface                                                RS485/RS232/Wi-fi/LAN
